TM5SDO8TA Schneider Electric , TM5SDO8TA ,Discrete output module, Modicon TM5, digital 8O, 2
SCHNEIDER ELECTRIC

Schneider Electric , TM5SDO8TA ,Discrete output module, Modicon TM5, digital 8O, 2 (TM5SDO8TA)

İndirim Oranı : %50 İndirim
KDV Dahil : €456,00
İndirimli : €190,00  + KDV
KDV Dahil : ₺7.919,19
TL Fiyat : ₺6.599,33(₺1.319,87 + KDV)
Barkod : 3595864074658
Favorilere Ekle
İstek Listeme Ekle
Karşılaştır
Fiyat Düşünce Haber Ver
Gelince Haber Ver
Tavsiye Et
Yorum Yaz
Sorular (0) ve Cevaplar (0)

Specifications



Main
range of product Modicon TM5
product or component type Discrete output module
discrete output number 8
discrete output type Transistor
Complementary
range compatibility Modicon M258
PacDrive LMC motion controller
Modicon LMC058
product compatibility Motion controller
PacDrive LMC Pro
PacDrive LMC Pro 2
Logic controller
PacDrive LMC Eco
output voltage 24 V DC
output voltage limits 20.4...28.8 V
discrete output logic Source
current per channel 2 A
maximum current per output common 8 A
colour White
peak output current 12 A
switching frequency <= 500 Hz resistive load
response time <= 300 µs from state 0 to state 1 for output
<= 300 µs from state 1 to state 0 for output
maximum leakage current 5 µA when switched off
protection type Short-circuit protection
Reverse polarity protection
Overload protection
isolation No insulation between channels
500 Vrms AC insulation between channel and bus
current consumption 0 mA at 24 V DC input/output
44 mA at 5 V DC bus
maximum power dissipation in W 1.5 W
local signalling 1 LED green for power supply
1 LED red for power supply
8 LEDs yellow for output status
electrical connection 1 wire
marking CE
net weight 0.025 kg
Environment
standards IEC 61131-2
CSA C22.2 No 142
CSA C22.2 No 213
UL 508
product certifications CULus
CSA
C-Tick
GOST-R
ambient air temperature for operation -10…55 °C without derating (horizontal installation)
-10…60 °C with derating factor (horizontal installation)
-10…50 °C (vertical installation)
ambient air temperature for storage -40…70 °C
relative humidity 5…95 % without condensation
IP degree of protection IP20 conforming to IEC 61131-2
pollution degree 2 conforming to IEC 60664
operating altitude 0...2000 m
storage altitude 0…3000 m
vibration resistance 1 gn at 8.4…150 Hz on DIN rail
3.5 mm at 5…8.4 Hz on DIN rail
shock resistance 15 gn for 11 ms
electromagnetic compatibility Electrostatic discharge immunity test, 4 kV on contact conforming to EN/IEC 61000-4-2
Electrostatic discharge immunity test, 8 kV in air conforming to EN/IEC 61000-4-2
Susceptibility to electromagnetic fields, 1 V/m 2...2.7 GHz conforming to EN/IEC 61000-4-3
Susceptibility to electromagnetic fields, 10 V/m 80...2000 MHz conforming to EN/IEC 61000-4-3
Electrical fast transient/burst immunity test, 1 kV I/O conforming to EN/IEC 61000-4-4
Electrical fast transient/burst immunity test, 1 kV shielded cable conforming to EN/IEC 61000-4-4
Electrical fast transient/burst immunity test, 2 kV power lines conforming to EN/IEC 61000-4-4
1.2/50 µs shock waves immunity test, 0.5 kV differential mode conforming to EN/IEC 61000-4-5
1.2/50 µs shock waves immunity test, 1 kV common mode conforming to EN/IEC 61000-4-5
Conducted RF disturbances conforming to EN/IEC 61000-4-6
Conducted and radiated emissions conforming to CISPR 11
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Weight 40.0 g
Package 1 Height 0.6 cm
Package 1 width 2 cm
Package 1 Length 11 cm
Unit Type of Package 2 S02
Number of Units in Package 2 97
Package 2 Weight 4.18 kg
Package 2 Height 15 cm
Package 2 width 30 cm
Package 2 Length 40 cm
Contractual warranty
Warranty 18 months
